Measuring crude oil presents unique challenges compared to measuring refined petroleum products. Crude oil is a complex mixture of hydrocarbons with widely varying physical and chemical properties depending on its source. It can contain significant amounts of dissolved gas (which separates as bubbles under reduced pressure), emulsified water, solid wax crystals, sand and corrosive compounds including hydrogen sulfide, CO₂, and organic acids. These characteristics make crude oil one of the most challenging fluids for flowmeter designers and operators, requiring careful consideration of meter technology, materials, and ancillary equipment.
Gas breakout—the formation of gas bubbles in the crude oil as pressure drops across the flowmeter—is a major concern. Positive displacement and turbine meters can over-read dramatically in the presence of gas because the meter registers the gas volume as liquid. To prevent gas breakout, the flowing pressure at the meter inlet must be maintained above the crude oil's bubble point pressure at the operating temperature. This is achieved through appropriate back pressure control valves downstream of the meter. Gas elimination equipment installed upstream can remove entrained gas before it reaches the meter. Automatic degassers and air eliminators are standard components of crude oil metering systems.
Water-in-crude measurements require additional considerations when the crude oil contains free water or is in the form of a water-in-oil emulsion. While the flowmeter measures the total volume of the mixed-phase stream, the commercial value of the crude is based on the water-free oil content. An online water cut monitor is used in conjunction with the flowmeter to determine the water fraction, allowing the net oil volume to be calculated. Coriolis flowmeters offer an advantage in crude oil metering because their density measurement can be used to track changes in water cut directly. Developing a robust crude oil metering system requires careful design of the metering skid, including dehydration, degassing, filtration, and a comprehensive instrumentation and control system.
