Project name | Parameter range |
Adapt temperature | -40℃～+55℃ |
Relative humidity | ≤95% |
Air pressure | 86～106KPa |
Voltage | AC220V±20% or AC380V±20% |
Frequency | (50±1)HZ√ (60±1)HZ |
Single range | 1～9999.99 ,1～999999.99(changeable) |
Range of cumulative number of classes | 0~99999999 |
Unit price setting range | 0～9999,0～999999(changeable) |
Accumulative range | 0~9999999999.99 |
Solenoid valve turn off setting range | 0~0.99L |
Nozzle No. | From1~10（OEM） |
Pump type | Suction pump/submersible pump |
Product Features
Electronic Calibration.
Function of locking pump.
Fueling time limit function.
With lock function.
With the function of total amount stop.
Optional voice reporting and printout functions.
Can set the decimal point for the display, so can be used in many country with different currency rate.
Can choose 7 digits for electromagnetic counter or 9 digits for Mechanical totalizer counter.
Leaves the communication ports, so it can communicate with the gas station management system.
Can add GPRS function ，connect with mobile phone to check data and set unit price anytime anywhere
Can add solar power function
Screen touch
Can add handshake function
TV medium
Can do OEM as required
