Project name | Parameter range |
Adapt temperature | -40℃～+55℃ |
Relative humidity | ≤95% |
Air pressure | 86～106KPa |
Voltage | AC220V±20% or AC380V±20% |
Frequency | (50±1)HZ√ (60±1)HZ |
Single range | 1～9999.99 ,1～999999.99(changeable) |
Range of cumulative number of classes | 0~99999999 |
Unit price setting range | 0～9999,0～999999(changeable) |
Accumulative range |
0~9999999999.99 |
Solenoid valve turn off setting range | 0~0.99L |
Nozzle No. | From1~10（OEM） |
Pump type | Suction pump/submersible pump |
Product Features with Display Configuration Options:
Display Configuration:
664 Configuration:
886 Configuration:
Electronic Calibration & Other Key Features:
Electronic Calibration: Ensures precise and accurate measurements.
Locking Pump Function: Provides security and control over fuel dispensing.
Fueling Time Limit Function: Allows customization of fueling durations.
Pump Lock Function: Prevents unauthorized use with a physical lock mechanism.
Total Amount Stop Function: Automatically halts dispensing when a predefined total amount is reached.
Optional Voice Reporting & Printout Functions: Enhances user convenience and record-keeping capabilities.
Decimal Point Setting: Adjustable to accommodate different currency rates globally.
Counter Options: Flexibility to choose between a 7-digit electromagnetic counter or a 9-digit mechanical totalizer counter based on requirements.
Communication Ports: Enables seamless integration with gas station management systems for efficient data transfer and monitoring.
